Description
| Brand | HP Enterprise |
| Model |
HPE DL380 Gen10 Plus CTO Server
|
| Country of Origin | USA |
| Country of Manufacture | Singapore |
| Processor |
2 x Intel Xeon-Gold 6326 2.9GHz 16-core 185W Processor for HPE
|
| Chipset |
Intel C621A Chipset
|
| Memory (RAM) |
128GB (4 x 32GB ) Dual Rank x4 DDR4-3200 CAS-22-22-22 Registered Smart Memory Kit
|
| Hard Disk Drive |
4 X HPE 2.4TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty 512e Multi Vendor HDD
|
| Cache Memory | 24 MB L3 Cache |
| Storage Controller |
Broadcom MegaRAID MR416i-a x16 Lanes 4GB Cache NVMe/SAS 12G Controller for HPE Gen10 Plus
|
| Storage Battery and Cable |
HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit
|
| Riser Kit |
HPE ProLiant DL380 Gen10 Plus x8/x16/x8 Primary FIO Riser Kit
|
| Network Interface Card |
Intel I350-T4 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
|
| Graphics |
Video modes up to 1920 x 1200@60Hz (32 bpp) 16MB Video Memory
|
| Power Supply |
2 x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
|
| System Fan(s) |
Hot-plug fans, 4 with single Processor and 6 with dual processor
|
| Expansion Slots |
Up to 8 PCIe slots
|
| Media Bays |
Standard: 8 SFF SAS/SATA HDD Bays; Upgradable up to 16 or 24 SFF SAS/SATA HDD
|
| Interfaces |
Serial: Optional, rear . Display Port: 1 optional front display port via Universal Media Bay.VGA: 1 standard, rear for all chassis. Network Ports : 4 x 1GbE embedded . HPE iLO Remote Management Network Port : 1 Gb Dedicated Rear. Front iLO Service Port : 1 standard . Micro SD Slot : Optional via HPE 32GB microSD RAID1 USB Boot Device . USB 3.0 : Up to 5 total: 1 front, 2 rear, 2 internal (secure), 2 optional USB 2.0 front via Universal Media Bay, or standard on 8LFF chassis . SID (Systems Insight Display) : Optional
|
| Remote Management |
HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
|
| OS Support |
3rd Generation Intel® Xeon® Scalable Processor Family
Windows Server 2019: Essentials, Standard, Datacenter Windows Server 2016: Essentials, Standard, Datacenter Microsoft Hyper-V Server: 2016 & 2019 VMware vSphere 6.7 U3 w/P03, 7.0 U2 Red Hat Enterprise Linux (RHEL) 7.9 & 8.2 - Includes KVM SUSE Linux Enterprise Server (SLES) 12 SP5, 15 SP2 (includes Xen & KVM) Ubuntu 20.04 LTS Oracle Linux 7.9 (UEK5 and UEK6) |
|
Security
|
Secure Boot and Secure Start enable for enhanced security
|
|
Embedded UEFI Shell
|
|
|
Operating system specific functionality
|
|
|
Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant
|
|
|
Support for > 2.2 TB (using GPT) boot drives
|
|
|
PXE boot support for IPv6 networks
|
|
| USB 3.0 Stack | |
|
Workload Profiles for simple performance optimization
|
|
|
UEFI Boot Mode only:
|
|
|
TPM 2.0 Support
|
|
|
iSCSI Software Initiator Support.
|
|
|
NVMe Boot Support
|
|
|
HTTP/HTTPs Boot support as a PXE alternative.
|
|
|
Platform Trust Technology (PTT) can be enabled.
|
|
|
Boot support for option cards that only support a UEFI option ROM
|
|
| Industry Standard Compliance |
ACPI 6.3 Compliant , PCIe 4.0 Compliant , WOL Support Microsoft® Logo certifications , PXE Support
VGA/Display Port, USB 3.0 Compliant (internal) USB 2.0 Compliant (external ports via SUV), Energy Star SMBIOS 3.2,Redfish API , IPMI 2.0 , Secure Digital 4.0 , TPM 1.20 and 2.0 Support , Advanced Encryption Standard (AES), Triple Data Encryption Standard (3DES) , SNMP v3 , TLS 1.2, DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP), Active Directory v1.0, ASHRAE A3/A4, EU Lot9, UEFI (Unified Extensible Firmware Interface Forum) 2.6, |
| Form Factor |
2U Rack form factor, Easy Install rail kit.
|
| Warranty |
HPE 3Y Tech Care Basic Service
|
Features of HPE Proliant DL380 G10 Plus Intel Xeon-Gold 6326 2x16c CTO Server
-
Server Model: The HPE Proliant DL380 series is known for its reliability and versatility. These servers are commonly used for various enterprise applications and are known for their robust performance.
-
Processor: The Intel Xeon-Gold 6326 is a high-performance server processor designed for data-intensive tasks and enterprise workloads. It is based on the Intel Xeon Scalable family of processors.
-
Processor Cores: You mentioned "2x16c," which likely means that this server includes two Intel Xeon-Gold 6326 processors, each with 16 cores, for a total of 32 processor cores. This configuration would provide substantial processing power for demanding applications.
-
Customizable Options (CTO): The "CTO" in the server's name likely stands for "Configure To Order." This means that customers can customize various aspects of the server, including memory, storage, network interfaces, and other hardware components, to meet their specific needs. This allows for flexibility in configuring the server to suit different workloads.
-
Memory: The amount of RAM (memory) that can be installed in the server may vary based on your configuration choices. HPE Proliant DL380 servers typically support a wide range of memory configurations, including different capacities and types of DDR4 ECC RAM.
-
Storage: These servers typically offer a variety of storage options, including support for SAS (Serial Attached SCSI) and SATA drives. They may also have multiple drive bays for both 2.5-inch and 3.5-inch drives, allowing for significant storage capacity.
-
Network Connectivity: HPE Proliant DL380 servers often come equipped with multiple Ethernet ports for network connectivity. They may also have options for additional network cards to support various network configurations.
-
RAID Support: Many HPE Proliant servers come with integrated RAID controllers, allowing for various RAID levels to enhance data redundancy and performance.
-
Management: HPE servers typically include management features such as Integrated Lights-Out (iLO) for remote server management, monitoring, and control.
-
Expansion Slots: These servers typically have multiple PCIe expansion slots for adding additional hardware components such as graphic cards, network adapters, or storage controllers.
What is the Price of HPE Proliant DL380 G10Plus Intel Xeon-Gold 6326 2x16c CTO Server in Bangladesh?
To know The latest price of HPE Proliant DL380 G10+ Intel Xeon-Gold 6326 2x16c CTO Server in Bangladesh Contact With Us. To buy this Server please visit our online store Silicon Computing Ltd. to get the best price in BD.
