Description
| Processor |
2xIntel® Xeon® Silver 4416+ 2G, 20C/40T, 16GT/s, 37.5M Cache, Turbo, HT (165W) DDR5-4000
|
| Chassis Type | 2.5" Chassis with up to 8/16 SAS/SATA Drives |
| Memory |
2X 32GB RDIMM, 4800MT/s Dual Rank (Can be Extended)
|
| HardDisk |
2X 480GB SSD SATA Read Intensive 6Gbps 512 2.5in Hot-plug AG Drive, 1 DWPD,
6X 2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive
|
| Raid Controller | PERC, H965i with rear load bracket |
| Motherboard |
PowerEdge R760xs Motherboard with Broadcom 5720 Dual Port 1Gb On-Board LOM
|
| Network Card |
Broadcom 5719 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile, V2, Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile |
| Embedded Systems Management | iDRAC9, Enterprise 16G |
| Power Supply |
Dual, Hot-Plug, Fully Redundant Power Supply (1+1), 1400W, Mixed Mode
|
| PCIe Riser |
Riser Config 1, Half Length, Low Profile, 3x16 + 1x8 + 2x16 (Gen5)
|
| Warranty | 3 years ProSupport |
Features of Dell PowerEdge R760xs (2X20 Core Silver) Rack Server
Processor and Performance:
- Processors: Dual 16-core Intel Xeon Silver processors.
- Clock Speed: Varies based on specific model, typically between 2.1 GHz to 3.2 GHz.
- Cache: Includes substantial L3 cache to enhance performance.
- Hyper-Threading: Supported for improved parallel processing.
Memory:
- Capacity: Up to 4 TB using DDR4 or DDR5 RAM (depending on configuration).
- Speed: Supports high-speed memory, typically ranging from 2400 MT/s to 3200 MT/s.
- Channels: Multiple memory channels for increased bandwidth.
Storage:
- Drive Bays: Configurable with up to 8-24 2.5” or 3.5” drives.
- RAID Options: Supports RAID 0, 1, 5, 6, 10, 50, 60 for data redundancy and performance.
- Storage Controllers: Integrated and add-on options for flexible storage solutions.
Connectivity:
- Network Interfaces: Multiple 1 GbE and/or 10 GbE ports, with additional NIC options.
- Expansion Slots: PCIe 3.0 or 4.0 slots for network cards, storage controllers, accelerators.
- I/O Ports: USB 3.0/3.1, VGA, serial, dedicated management ports.
Management and Security:
- iDRAC: Integrated Dell Remote Access Controller for remote management.
- Security Features: TPM 2.0, Secure Boot, System Lockdown, Secure Erase.
- Monitoring: Comprehensive hardware monitoring and alerting.
Power and Cooling:
- Power Supply Units (PSUs): Redundant hot-swappable units (500W, 750W, 1100W).
- Cooling: Advanced solutions with hot-swappable fans, thermal management.
Software and OS Support:
- Operating Systems: Supports Windows Server, Linux, VMware ESXi.
- Virtualization: Optimized for VMware, Hyper-V, and other hypervisors.
Form Factor:
- Rack Unit: 2U rack-mountable chassis.
What is the Price of Dell PowerEdge R760xs (2X20 Core Silver) Rack Server in Bangladesh?
To know the latest price of Dell PowerEdge R760xs (2X20 Core Silver) Rack Server in Bangladesh Contact With us. To buy this Server please visit our online store Silicon Computing Ltd. to get the best price in BD.
