| US-FCC |
CH 1–11, 36–64, 100–144, 149–165
|
| ISED Canada |
CH 1–11, 36–64, 100–116, 149–165
|
| EU-ETSI | CH 1–13, 36–64, 100–140 |
| ROW |
CH 1–13, 36–64, 100–144, 149–165 2400-2483.5 MHz, 5150-5850 MHz
|
| DFS | Channels to be released later |
| Radios |
1 x 5 GHz radio (802.11 a/n/ac Wave 2), 2×2 1 x 2.4 GHz (802.11 b/g/n), 2X2 SU-MIMO / MU-MIMO: 2 streams
|
| Wi-Fi | 802.11 a/b/g/n/ac |
| SSID Security |
WPA2 (802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK, Open
|
| Max PHY Rate |
2.4 GHz: 400 Mbps 5 GHz: 867 Mbps
|
| Ethernet |
One IEEE Gigabit Ethernet auto sensing
|
| Antenna |
Internal omni-directional 2.4 GHz: 5.24 dBi 5 GHz: 5.47 dBi
|
| Max EIRP |
2.4 GHz: 29.50 dBm 5 GHz: 30 dBm (EIRP limited by country regulations)
|
| WLAN |
256 clients, 32 SSIDs (16 per radio) WPA-TKIP, WPA2 AES, 802.1x, 802.11w PMF
|
| Power |
802.3af powered device Typical load: 9 W, Max: 11.5 W
|
| Mounting |
Desktop, Wall, cieling tile mount – included T-bar mount 14 mm x 24 mm x 38 mm (0.55 in x 0.94 in x 1.5 in) Ceiling Tile mount included Kensington lock slot
|
| Dimensions |
180 mm x 180 mm x 42mm (7.09 in x 7.09 in x 1.65 in)
|
| Weight | 384 g (0.85 lb) |
| LEDs |
Single Tri-color LED (amber, blue, green)
|
| Ambient Operation Temperature | 0ºC to 50ºC (32ºF to 122ºF |
| Storage Temperature | 40ºC to 70ºC (-40ºC to 158ºF) |
| Humidity | 95% RH non-condensing |
| MTBF | 1.5m hours |
| Certifications |
Wi-Fi Alliance 802.11 a/b/g/n/ac, Passpoint 2.0 FCC, ETSI, CE, EN 60601-1-2, IEC62368 UL2043
|
Features of Cambium CnPilot E410 Wi-Fi 5 Indoor Access Point
The Cambium Networks CnPilot E410 is an indoor Wi-Fi 5 (802.11ac) access point designed to provide high-performance wireless connectivity in various indoor environments. It’s part of Cambium Networks’ CnPilot series, which focuses on delivering reliable and cost-effective wireless solutions for both enterprises and service providers.
Key features and specifications of the Cambium CnPilot E410 Access Point:
-
Wireless Standard: Supports the Wi-Fi 5 (802.11ac) standard, offering faster data rates, improved capacity, and enhanced overall performance compared to older Wi-Fi standards.
-
Dual-Band Operation: The E410 operates on both the 2.4 GHz and 5 GHz frequency bands, allowing for better network optimization and reduced interference.
-
MU-MIMO (Multi-User, Multiple Input, Multiple Output): MU-MIMO technology enables the access point to communicate with multiple devices simultaneously, improving overall network efficiency and user experience.
-
High Data Rates: The access point supports data rates of up to 1.167 Gbps, providing ample bandwidth for demanding applications such as streaming, video conferencing, and online gaming.
-
Indoor Deployment: Designed for indoor installations, the E410 is suitable for a wide range of environments, including offices, retail stores, hospitality venues, schools, and more.
-
Advanced Security: The access point features various security mechanisms to protect the network and user data, including WPA3 encryption, MAC filtering, and VLAN support.
-
Sleek Design: The E410 has a compact and aesthetically pleasing design, making it suitable for deployments where appearance matters.
-
Power over Ethernet (PoE): The access point supports Power over Ethernet, allowing both data and power to be delivered over a single Ethernet cable, simplifying installation and reducing cable clutter.
-
Cloud Management: Cambium Networks offers cloud-based management for their access points, making it easier to monitor, configure, and manage multiple devices remotely.
-
Guest Access and Captive Portal: The E410 supports guest access features and captive portal functionality, allowing you to provide controlled internet access for visitors while capturing useful data.
-
Quality of Service (QoS): QoS features ensure that critical applications and services receive priority over less important traffic, optimizing the network’s performance for various use cases.
-
Scalability: The access points can be easily scaled to accommodate growing network demands by adding more units and managing them centrally.
What is the Price of Cambium CnPilot E410 Wi-Fi 5 Indoor Access Point in Bangladesh?
To know the latest price of Cambium CnPilot E410 Wi-Fi 5 Indoor Access Point in Bangladesh contact with us. To buy this please visit our online store Silicon Computing Ltd. to get the best price in BD.
